Setting up Gitea (GitHub-like) Actions on my K3S Cluster
In my previous post I set up a local git server on my K3S cluster using Gitea. While it’s nice to have a local Git server, my real goal is to set up continuous delivery on my local projects. Gitea supports pipelines using Gitea Actions, which has near feature parity with GitHub Actions. Getting Gitea Actions up and running took a bit more work than I expected.
Preparing Gitea to run actions
Enable Actions in Gitea configuration
Gitea does not have Actions enabled by default. Since I have Gitea installed in my K3S cluster using a Helm chart, I updated my Helm chart and re-applied it.
I’ll go into more detail later, but in this step I also enabled Gitea’s built-in container registry by enabling the packages option.
gitea:
config:
actions:
ENABLED: true
packages:
ENABLED: true
# Database pod configuration
postgresql-ha:
postgresql:
livenessProbe:
initialDelaySeconds: 300
timeoutSeconds: 10
failureThreshold: 6
readinessProbe:
initialDelaySeconds: 300
timeoutSeconds: 10
failureThreshold: 6Since Helm charts are declarative and the application of Helm charts is idempotent, I added the new configuration to the existing configuration. When the upgrade is applied, the database configuration that has already been applied won’t be re-applied. This is convenient, as I can keep a record of my configuration changes and my current state in source control.
I applied the new values using helm upgrade.
helm upgrade gitea gitea-charts/gitea -f values.yaml -n <namespace>Install Docker Engine prereq for Gitea runner
Gitea uses an act runner to run the actions, independent of the other parts of Gitea. act is an open source tool that can be used to run GitHub Actions locally. Some of the actions in GitHub Actions (and therefore Gitea Actions) involve pulling or building container images, which act does by communicating with a Docker daemon via the Docker socket. My install of K3S uses the default container runtime for K3S, containerd, so I needed to install Docker Engine on my nodes before setting up my runner.
This does mean that my nodes will have both containerd (used by K3S) and Docker Engine (used by the act runner) running concurrently, but this should not be a problem with these particular Pis, as they have 8GB of RAM. With a smaller amount of RAM I probably would put in the work to switch my K3S install to use Docker Engine for its own container runtime, but it’s not necessary in this case.
In my previous post I described managing the configuration of my nodes using Ansible, so I updated the playbook:
---
- name: Configure k3s cluster nodes
hosts: k3s_cluster
become: true
vars:
nfs_server: "192.168.50.X"
nfs_mount_path: "/mnt/tank/k3s"
tasks:
- name: Update apt cache
apt:
update_cache: true
cache_valid_time: 3600
- name: Install required packages
apt:
name:
- nfs-common
- open-iscsi
- curl
- git
state: present
- name: Enable and start rpcbind
systemd:
name: rpcbind
enabled: true
state: started
- name: Test NFS mount is reachable
command: "showmount -e {{ nfs_server }}"
register: nfs_exports
changed_when: false
failed_when: false
- name: Show NFS exports from TrueNAS
debug:
var: nfs_exports.stdout_lines
# New Docker install instructions
- name: Download Docker install script
get_url:
url: https://get.docker.com
dest: /tmp/get-docker.sh
mode: '0755'
- name: Install Docker
command: /tmp/get-docker.sh
args:
creates: /usr/bin/docker
- name: Enable and start Docker
systemd:
name: docker
enabled: true
state: started
- name: Add user to docker group
user:
name: "{{ ansible_user }}"
groups: docker
append: true
- name: Configure Docker daemon
copy:
dest: /etc/docker/daemon.json
content: |
{
"log-driver": "json-file",
"log-opts": {
"max-size": "10m",
"max-file": "3"
}
}
notify: restart docker
handlers:
- name: restart docker
systemd:
name: docker
state: restartedSimilarly to the Helm values file, this playbook is idempotent and declarative. Ansible will run all of the tasks, but because tasks like the Docker install use creates: /usr/bin/docker, they are skipped when the target state already exists. The net effect is that only the apt cache update and the Docker Engine installation steps will do any real work.
ansible-playbook -i inventory.ini setup-nodes.ymlEnabling the Gitea built-in Container Registry
Kubernetes always pulls containers from a registry, so if I want to have the Gitea actions pipelines to deploy applications to my K3S cluster, I needed a container registry. Gitea actually has a built-in container registry, which I enabled earlier using the packages option in the Helm configuration. But for the Docker Engine on my nodes to have access to this registry I need to do some work I skipped before: setting up a local domain name and enabling SSL.
Enabling SSL for the gitea registry
Docker also requires HTTPS for accessing the container registry. Though there are docker settings that should allow you to access a registry without SSL by adding it to a list of Insecure Registries, I wasn’t able to get it to work. While I’m sure I could get there, this is a good example of software nudging me toward making the better choice: enabling SSL for my registry.
Since I’m only using my K3S cluster internally, I can use a self-signed certificate rather than getting a root certificate from a certificate authority. I did this on my host computer using step, a CLI tool from Smallstep for PKI operations.
step certificate create "K3s Home CA" ca.crt ca.key --profile root-ca --no-password --insecureTo enable SSL with the services on my K3S cluster, I installed cert-manager using Helm:
helm repo add jetstack https://charts.jetstack.io
helm repo update
helm install cert-manager jetstack/cert-manager --namespace cert-manager --create-namespace --set crds.enabled=trueI stored the root certificate as a Kubernetes secret:
kubectl create secret tls k3s-ca-secret --cert=$HOME/k3s-ca/ca.crt --key=$HOME/k3s-ca/ca.key -n cert-managerI created a ClusterIssuer using that Certificate Authority and stored the config as cluster-issuer.yaml.
apiVersion: cert-manager.io/v1
kind: ClusterIssuer
metadata:
name: k3s-ca-issuer
spec:
ca:
secretName: k3s-ca-secretkubectl apply -f cluster-issuer.yamlThen I created a certificate for my registry domain using the config file registry-certificate.yaml:
apiVersion: cert-manager.io/v1
kind: Certificate
metadata:
name: registry-cert
namespace: kube-system
spec:
secretName: registry-tls
issuerRef:
name: k3s-ca-issuer
kind: ClusterIssuer
dnsNames:
- registry.home.stuffkubectl apply -f registry-certificate.yamlFinally, I updated the Traefik Gateway to support https. There is a new URL in this configuration, registry.home.stuff, that I will be defining in the next section.
apiVersion: gateway.networking.k8s.io/v1
kind: Gateway
metadata:
name: traefik-gateway
namespace: kube-system
spec:
gatewayClassName: traefik
listeners:
- name: http
protocol: HTTP
port: 8000
allowedRoutes:
namespaces:
from: All
- name: websecure-registry
protocol: HTTPS
port: 8443
hostname: registry.home.stuff
tls:
mode: Terminate
certificateRefs:
- name: registry-tls
namespace: kube-system
allowedRoutes:
namespaces:
from: All
- name: tcp
protocol: TCP
port: 3000
allowedRoutes:
namespaces:
from: Allkubectl apply -f traefik-gateway.yaml -n kube-systemSetting up the local domain name
I have been using the node names as the domain for my services on K3S along with various paths. For example, http://raspberrypi1/gitea would navigate to my Gitea instance. However, Docker treats single-part domains as a path to a repository on docker.io, so if I tried to use raspberrypi1/registry as the address for my registry, Docker would resolve it as docker.io/raspberrypi1/registry. Hence I needed a full 3-part domain name.
With my network configuration, I can change this domain name using the ASUS Router configuration front-end. I logged into the router, then navigated to LAN under Advanced settings. There I set the domain name to home.stuff under the LAN IP tab. Under the DHCP Server tab I added a DNS entry mapping the hostname registry to the IP address of raspberrypi1. With this router, that gives the raspberrypi1 node the domain name registry.home.stuff.
The Traefik Gateway that I set up in my K3S cluster earlier allows me to use the domains associated with any of the nodes for any of the HTTP Routes I define on the cluster, so I could now use the registry.home.stuff domain name for an HTTP route to the Gitea registry. I used the following gitea-registry-httproute.yaml file:
apiVersion: gateway.networking.k8s.io/v1
kind: HTTPRoute
metadata:
name: gitea-registry
namespace: gitea
spec:
parentRefs:
- name: traefik-gateway
namespace: kube-system
sectionName: websecure-registry
hostnames:
- registry.home.stuff
rules:
- matches:
- path:
type: PathPrefix
value: /
backendRefs:
- name: gitea-http
port: 3000I applied it using kubectl:
kubectl apply -f gitea-registry-httproute.yaml -n giteaI used a similar HTTPRoute to map my gitea service to gitea.home.stuff.
Updating node configurations with CA and registry information
I needed each of my nodes to trust my self-signed certificates for the TLS functions in Docker and containerd. Additionally I needed containerd on each node to be configured for the new registry. Using Ansible I applied the changes to each of the nodes. I added the following sections to my playbook.
tasks:
...
- name: Copy CA certificate to nodes
copy:
src: "{{ lookup('env', 'HOME') }}/k3s-ca/ca.crt"
dest: /usr/local/share/ca-certificates/k3s-home-ca.crt
mode: '0644'
- name: Update CA certificates
command: update-ca-certificates
changed_when: false
- name: Configure containerd for registry
copy:
dest: /etc/rancher/k3s/registries.yaml
content: |
mirrors:
"registry.home.stuff":
endpoint:
- "https://registry.home.stuff"
configs:
"registry.home.stuff":
tls:
ca_file: /usr/local/share/ca-certificates/k3s-home-ca.crt
notify: restart k3s
handlers:
...
- name: restart k3s
systemd:
name: "{{ 'k3s' if inventory_hostname in groups['k3s_server'] else 'k3s-agent' }}"
state: restartedThis copied my CA certificate from my local machine to the nodes, updated the CA certificates on the nodes, and configured containerd to use the new container registry. I applied the changes using Ansible:
ansible-playbook -i inventory.ini setup-nodes.ymlCreate runner in Gitea
I had one more prerequisite before creating my Gitea runner, in the form of a token used by the runner to authenticate with Gitea. Gitea runners can be on the Instance, Organization, or Repository level. Since I only have one organization on my Gitea instance, an instance-level runner and an organization-level runner would cover the same set of repositories, so the distinction doesn’t matter for me. I’m fine with all of my repositories sharing the same runner (for now), so I created the token for my runner using the following steps.
- Log in as Site Admin to Gitea
- Go to Site Administration > Actions > Runners > Create Runner
- Copy the created token
To give my runner access to the token, I stored it as a secret in my K3S cluster.
kubectl create secret generic gitea-runner-secret --from-literal=token=<my-runner-token> -n giteaSet up the Gitea runner
With the Docker Engine dependency resolved, I set up a runner to execute the Gitea Action jobs. This took some trial and error, as I found that the default gitea/act_runner:latest image would not trust my self-signed certificate. Rather than asking the runner to trust the certificate anew on every run, I created a custom runner image named Dockerfile.runner that copied in the cert from a local location and updated the CA certificates.
FROM gitea/act_runner:latest
COPY ca.crt /usr/local/share/ca-certificates/k3s-home-ca.crt
RUN apk add --no-cache ca-certificates && update-ca-certificatesI pushed this custom runner image to the new registry:
docker login registry.home.stuff
docker build -f Dockerfile.runner -t registry.home.stuff/kckempf/act-runner:latest .
docker push registry.home.stuff/kckempf/act-runner:latestI also needed to tell the runner to use the host network for job containers, as the job containers running in Docker cannot reach cluster-internal hostnames without access to the host network. So, I added a ConfigMap to create a config file with the setting container: network: host:
apiVersion: v1
kind: ConfigMap
metadata:
name: gitea-runner-config
namespace: gitea
data:
config.yaml: |
runner:
fetch_timeout: 5s
fetch_interval: 2s
container:
network: hostWith those resources defined, I could create a runner that has access to the local container registry at registry.home.stuff and that trusts the certificate authority that signed its certificate.
apiVersion: apps/v1
kind: Deployment
metadata:
name: gitea-runner
namespace: gitea
spec:
replicas: 1
selector:
matchLabels:
app: gitea-runner
template:
metadata:
labels:
app: gitea-runner
spec:
containers:
- name: runner
image: registry.home.stuff/kckempf/act-runner:latest
env:
- name: GITEA_INSTANCE_URL
value: https://gitea.home.stuff
- name: GITEA_RUNNER_REGISTRATION_TOKEN
valueFrom:
secretKeyRef:
name: gitea-runner-secret
key: token
- name: CONFIG_FILE
value: /config/config.yaml
volumeMounts:
- name: docker-socket
mountPath: /var/run/docker.sock
- name: runner-data
mountPath: /data
- name: runner-config
mountPath: /config
volumes:
- name: docker-socket
hostPath:
path: /var/run/docker.sock
type: Socket
- name: runner-data
emptyDir: {}
- name: runner-config
configMap:
name: gitea-runner-configI applied the change using kubectl.
kubectl apply -f gitea-runner.yamlConclusion: Finally ready for that pipeline
Getting Gitea from its vanilla install into a state where it is ready to publish my projects to my K3S cluster using Gitea Actions took a fair bit more work than I was expecting, but I’m happy with where I ended up. After all of that, here is where the project stands:
- Gitea Actions is active on my Gitea instance
- A Gitea Runner is ready to spin up and run Docker containers in the pipelines
- Gitea has its native container registry up and running and available to both K3S’s containerd container runtime and the Gitea Runner’s Docker Engine
- I now have full 3-part domain names available for my K3S cluster’s services
- I now have SSL enabled for any of the services on my K3S cluster
The next step is to finally publish to my K3S cluster via Gitea!
